Product Specification

System:

Processor: Intel small-core N series is optional

System memory: DDR5 SODI MM x1, supports up to 32GB

Network: 2 x RJ45 Intel 2.5G i226V

I/O interface:

2 x USB 3.2 Gen2, 3 x USB2.0, 1 x USB Type-C(display support)

1 x HDMI 2.0, 1 x DP 1.4, 1 x USB Type-C

1 x Power Button

Supports 12V-19V power input

1 x headphone jack, 1 x microphone

Storage: 2 x M.2 NVME(PCIE 3.0 x2, where one SSD supports M.2 SATA)

Expansion slot: 1 x M.2 Wi-Fi

System support: Windows? 10, Windows? 11, Linux

Other: network wake up, call boot, timed boot, diskless start

Power Supply:

Power input: 12V-19V

Structure:

Material: Aluminum + ABS

Installation mode: Supports desktop and wall mount

Dimensions: 135 x 125 x 40 mm

Weight: 1.0 Kg

Working environment:

Storage temperature: -30℃ to +70℃

Operating temperature: -20℃ to +60℃

Storage humidity: 10%~90% @30℃, no condensation
